Consumer SSD E2000 adopts M.2 interface, advanced SSD control computing chip and 3D NAND flash to effectively improveR/W speed and ensure data security. It applies to personal computer and small-size proxy server to providing stable and high-speed service. It can also improve the high-end gaming experience and 3D graphics editing performance.

Available Models

HS-SSD-E2000 256GB

HS-SSD-E2000 512GB

HS-SSD-E2000 1024GB

HS-SSD-E2000 2048GB

Typical Application

● PC (notebook and desktop)

● Small-size proxy sever

Features and Functions

● High R/W Speed

Supports PCIe and NVMe

Max. read speed up to 3300 MB/s

● 3D NAND

Adopts 3D NAND flash to optimize capacity, performance and

stability

● Shockproof

No mechanical structure

Adopts electronic chips control

High data security

● M.2Interface

Specifications:

• Model HS-SSD-E2000
• Capacity 256 GB 512 GB 1024 GB 2048GB
• Form Factor M.2 (NGFF)
• Interface PCIe Gen 3 x 4, NVMe
• DRAM Cache Memory support
• Dimensions 80.15 mm × 22.15 mm × 2.38 mm
• Max. sequential 128 K read speed 3000 MB/s 3400 MB/s 3300 MB/s 3300 MB/s
• Max. sequential 128 K write speed 1300 MB/s 2600 MB/s 2800 MB/s 3000 MB/s
• Max. random 4 K read IOPS 194 K 195 K 193 K 115 K
• Max. random 4 K write IOPS 266 K 265 K 215 K 325 K
• Power
• consumption
• Read (RMS max.) 3.96 W 3.96 W 3.96 W 3.96 W
• Write (RMS max.) 6.4 W 7W 7.2W 7.2 W
• Endurance (TBW) 160 TB 320 TB 640 TB 1280 TB
• NAND flash memory 3D TLC
• Weight ≤ 8 g
• MTBF (Mean Time between Failures)2,000,000 h
• Operation temperature 0 °C to 70 °C (32 °F to 158 °F)
• Storage temperature -40 °C to +85 °C (-40 °F to +185 °F)
• Operation humidity 5% to 95% (no condensation)
• Limited warranty period 3 years
